LAPP Mobile Charging Station Basic 11 kW, Type 2 to CEE, 6 m

Mobile 11 kW charging station for electric cars and plug-in hybrids: The LAPP Basic connects vehicles with a Type 2 charging connection directly to a red, five-pin CEE socket. The 6 m long cable is suitable as a flexible charging solution at home, at work and on the go.

LAPP Mobile Charging Station Basic at a glance

• Charging power: up to 11 kW
• Vehicle connector: Type 2 coupling
• Mains connection: CEE plug, red, 5-pin, three-phase
• Rated current: 16 A
• Rated voltage: 440 V
• Cable length: 6 m
• Cable type: ÖLFLEX CHARGE 5G2,5+1x0,5
• Protection class: IP67
• Temperature range: −25 to +45 °C
• Suitable for: battery electric vehicles and plug-in hybrids with Type 2 connection

Charge electric cars flexibly at a CEE socket

The mobile charging station is connected to a suitable red CEE socket and enables three-phase charging with up to 11 kW. The integrated control and protection box (IC-CPD) monitors the charging process and provides overcurrent and overtemperature protection functions, among others. A protective cap protects the Type 2 coupling during transport and storage.

For fleets, company cars and on the go

With a 6 m cable length, the charging station offers sufficient freedom of movement between the CEE connection and the vehicle. It is suitable for companies, workshops, field service vehicles and as a mobile addition to a permanently installed wallbox. Thanks to IP67 protection, the system is protected against dust and temporary immersion.

Important note on connection

This version has a red, five-pin CEE plug and is not intended for a conventional Schuko household socket. The CEE connection used must be professionally installed, suitable for the load and properly fused. The actually achievable charging power also depends on the vehicle and the existing electrical installation.

Frequently asked questions about the LAPP Basic 11 kW

Which vehicles can be charged with the charging station?

It is suitable for electric cars and plug-in hybrids with a Type 2 vehicle connection.

Which socket is required?

A red, five-pin and three-phase CEE socket for 16 A is required. Direct connection to a Schuko socket is not possible with this variant.

How fast does the mobile charging station charge?

The maximum charging power is 11 kW. How quickly the vehicle actually charges depends on its onboard charger, the battery level and the electrical installation.

Can the charging station be used outdoors?

The product is rated IP67. However, connections and plug connections must still be used according to the manufacturer's instructions and protected from damage.

Manufacturer No.: 5555921007
Wiepa Article No.: 481115500
Scope of delivery: 1 mobile charging station LAPP Basic with Type 2 coupling, CEE plug and protective cap
